Scientists At MTU Develops Brand-New Way To Synthesize Sodium-Embedded Carbon Nanowalls

A little sodium goes a long way. At least that’s the case in carbon-based energy technology. Specifically, embedding sodium in carbon materials can tremendously improve electrodes.

Scientists at Michigan Technological University invented a method to take a material out of theory and make it into a real electrode. They ran tests on the sodium-embedded carbon and it performed better than graphene in dye-sensitized solar cells and supercapacitors. The new material can improve electrode performance in energy devices.

A research team led by Yun Hang Hu, the Charles and Carroll McArthur Professor of materials science and engineering at Michigan Tech, created a brand-new way to synthesize sodium-embedded carbon nanowalls. Previously, the material was only theoretical and the journal Nano Letters recently published this invention.

High electrical conductivity and large accessible surface area, which are required for ideal electrode materials in energy devices, are opposed to each other in current materials. Amorphous carbon has low conductivity but large surface area. Graphite, on the other hand, has high conductivity but low surface area. Three-dimensional graphene has the best of both properties — and the sodium-embedded carbon invented by Hu at Michigan Tech is even better.

“Sodium-embedded carbon’s conductivity is two orders of magnitude larger than three-dimensional graphene,” Hu says. “The nanowall structure, with all its channels and pores, also has a large accessible surface area comparable to graphene.”

This is different from metal-doped carbon where metals are simply on the surface of carbon and are easily oxidized; embedding a metal in the actual carbon structure helps protect it. To make such a dream material, Hu and his team had to create a new process. They used a temperature-controlled reaction between sodium metal and carbon monoxide to create a black carbon powder that trapped sodium atoms. Furthermore, in collaboration with researchers at University of Michigan and University of Texas at Austin, they demonstrated that the sodium was embedded inside the carbon instead of adhered on the surface of the carbon. The team then tested the material in several energy devices.

In the dye-sensitized solar cell world, every tenth of a percent counts in making devices more efficient and commercially viable. In the study, the platinum-based solar cell reached a power conversion efficiency of 7.89 percent, which is considered standard. In comparison, the solar cell using Hu’s sodium-embedded carbon reached efficiencies of 11.03 percent.

Supercapacitors can accept and deliver charges much faster than rechargeable batteries and are ideal for cars, trains, elevators and other heavy-duty equipment. The power of their electrical punch is measured in farads (F); the material’s density, in grams (g), also matters.

Activated carbon is commonly used for supercapacitors; it packs a 71 F g-1 punch. Three-dimensional graphene has more power with a 112 F g-1 measurement. Sodium-embedded carbon knocks them both out of the ring with a 145 F g-1 measurement. Plus, after 5,000 charge/discharge cycles, the material retains a 96.4 percent capacity, which indicates electrode stability.

Hu says innovation in energy devices is in great demand. He sees a bright future for sodium-embedded carbon and the improvements it offers in solar tech, batteries, fuel cells, and supercapacitors.

Source: Michigan Technological University
